Setting Up a MicroK8s Kubernetes Cluster on Ubuntu 24

MicroK8s is Canonical’s lightweight Kubernetes distribution that gives you a full-featured Kubernetes cluster without the complexity of traditional setups. Unlike heavyweight solutions like kubeadm or managed services, MicroK8s runs locally on your Ubuntu machine, making it perfect for development, testing, edge computing, and IoT deployments. In this guide, you’ll learn how to set up a complete MicroK8s cluster on Ubuntu 24, configure essential add-ons, and troubleshoot common issues that’ll save you hours of head-scratching.

How MicroK8s Works Under the Hood

MicroK8s packages all Kubernetes components into a single snap package, eliminating the dependency hell that usually comes with Kubernetes installations. Instead of managing separate containers for the API server, etcd, kubelet, and other components, MicroK8s runs everything as systemd services within the snap’s confined environment.

The architecture is surprisingly elegant:

Containerd handles container runtime (no Docker daemon needed)
Dqlite replaces etcd for lightweight distributed state management
Calico provides networking by default
Built-in DNS with CoreDNS for service discovery
Add-ons system for extending functionality without manual YAML wrestling

This design makes MicroK8s consume significantly fewer resources compared to traditional Kubernetes distributions while maintaining full API compatibility.

Prerequisites and System Requirements

Before diving in, let’s check if your Ubuntu 24 system is ready:

Component	Minimum	Recommended
RAM	2GB	4GB+
CPU	2 cores	4 cores
Storage	10GB	20GB+
Network	Internet access	Static IP preferred

Update your system and install snapd if it’s not already present:

sudo apt update && sudo apt upgrade -y
sudo apt install snapd -y
sudo systemctl enable --now snapd.socket

Step-by-Step MicroK8s Installation

Installing MicroK8s is refreshingly straightforward compared to the usual Kubernetes installation nightmare. Here’s the complete process:

Install MicroK8s

# Install the latest stable version
sudo snap install microk8s --classic

# Or install a specific version
sudo snap install microk8s --classic --channel=1.28/stable

Configure User Permissions

Add your user to the microk8s group to avoid typing sudo constantly:

sudo usermod -a -G microk8s $USER
sudo chown -f -R $USER ~/.kube
newgrp microk8s

Log out and back in, or use newgrp microk8s to refresh group membership.

Verify Installation

# Check cluster status
microk8s status --wait-ready

# Get node information
microk8s kubectl get nodes

# Check system pods
microk8s kubectl get pods -A

You should see output similar to:

NAME             STATUS   ROLES    AGE   VERSION
ubuntu-desktop   Ready    <none>   2m    v1.28.3

Essential Add-ons Configuration

MicroK8s shines with its add-on system. Enable the most useful ones for development:

# Enable DNS (essential for service discovery)
microk8s enable dns

# Enable dashboard for web UI
microk8s enable dashboard

# Enable storage class
microk8s enable hostpath-storage

# Enable ingress controller
microk8s enable ingress

# Enable registry for local image storage
microk8s enable registry

# Enable metrics server for resource monitoring
microk8s enable metrics-server

Check enabled add-ons:

microk8s status

Setting Up kubectl Access

You can use MicroK8s’s built-in kubectl or configure your system’s kubectl:

Option 1: Use microk8s kubectl directly

# Create an alias for convenience
echo 'alias kubectl="microk8s kubectl"' >> ~/.bashrc
source ~/.bashrc

Option 2: Configure system kubectl

# Install kubectl if not present
sudo apt install kubernetes-client -y

# Export MicroK8s config
microk8s config > ~/.kube/config

# Verify connection
kubectl get nodes

Real-World Examples and Use Cases

Let’s deploy a practical example to test your cluster:

Deploy a Sample Application

# Create a deployment
kubectl create deployment nginx --image=nginx:latest

# Expose the deployment
kubectl expose deployment nginx --port=80 --type=NodePort

# Check the service
kubectl get services

# Get the node port
kubectl get service nginx -o jsonpath='{.spec.ports[0].nodePort}'

Access your application at http://localhost:<nodeport>.

Deploy with Ingress

Create a more realistic setup with ingress:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: hello-world
spec:
  replicas: 2
  selector:
    matchLabels:
      app: hello-world
  template:
    metadata:
      labels:
        app: hello-world
    spec:
      containers:
      - name: hello-world
        image: gcr.io/google-samples/hello-app:1.0
        ports:
        - containerPort: 8080
---
apiVersion: v1
kind: Service
metadata:
  name: hello-world-service
spec:
  selector:
    app: hello-world
  ports:
  - port: 8080
    targetPort: 8080
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: hello-world-ingress
spec:
  rules:
  - host: hello.local
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: hello-world-service
            port:
              number: 8080

Apply this configuration:

kubectl apply -f hello-world.yaml

# Add to /etc/hosts
echo "127.0.0.1 hello.local" | sudo tee -a /etc/hosts

# Test
curl http://hello.local

Multi-Node Cluster Setup

MicroK8s can create multi-node clusters easily. On your first node (already set up):

# Generate join token
microk8s add-node

On additional Ubuntu 24 nodes:

# Install MicroK8s
sudo snap install microk8s --classic

# Join the cluster (use token from previous command)
microk8s join <master-ip>:25000/<token>

Verify multi-node setup:

microk8s kubectl get nodes -o wide

Comparison with Other Kubernetes Distributions

Feature	MicroK8s	K3s	kubeadm	Kind
Installation complexity	Very Easy	Easy	Complex	Easy
Resource usage	Low	Very Low	High	Medium
Production ready	Yes	Yes	Yes	No
Add-ons system	Excellent	Good	Manual	Limited
Multi-node support	Yes	Yes	Yes	No
Update mechanism	Snap channels	Binary replacement	Manual	Image updates

Common Issues and Troubleshooting

MicroK8s Not Starting

If MicroK8s fails to start:

# Check snap services
sudo systemctl status snap.microk8s.*

# Restart MicroK8s
microk8s stop
microk8s start

# Check logs
journalctl -u snap.microk8s.daemon-cluster-agent.service -f

DNS Resolution Issues

Common DNS problems and fixes:

# Test DNS
kubectl run -it --rm debug --image=busybox --restart=Never -- nslookup kubernetes.default

# If DNS fails, restart CoreDNS
microk8s kubectl rollout restart deployment/coredns -n kube-system

Storage Issues

If pods can’t mount volumes:

# Check storage class
kubectl get storageclass

# Verify hostpath-storage is enabled
microk8s status

# Check available disk space
df -h

Firewall Configuration

Ubuntu’s UFW might block MicroK8s traffic:

# Allow MicroK8s ports
sudo ufw allow in on cni0
sudo ufw allow out on cni0
sudo ufw default allow routed

Performance Optimization and Best Practices

Resource Limits

Always set resource limits in production:

apiVersion: v1
kind: Pod
spec:
  containers:
  - name: app
    image: nginx
    resources:
      requests:
        memory: "64Mi"
        cpu: "250m"
      limits:
        memory: "128Mi"
        cpu: "500m"

Cluster Monitoring

Enable monitoring stack:

# Enable Prometheus and Grafana
microk8s enable prometheus

# Access Grafana
kubectl port-forward -n monitoring service/prometheus-grafana 3000:80

Backup and Maintenance

Regular backup practices:

# Backup cluster state
microk8s kubectl get all --all-namespaces -o yaml > cluster-backup.yaml

# Backup snap data
sudo snap save microk8s

Security Considerations

Harden your MicroK8s installation:

# Enable RBAC (usually enabled by default)
microk8s enable rbac

# Create non-admin user
kubectl create serviceaccount developer
kubectl create clusterrolebinding developer --clusterrole=view --serviceaccount=default:developer

# Use network policies
microk8s enable cilium

Advanced Configuration

Custom Add-ons

Create custom add-ons directory:

sudo mkdir -p /var/snap/microk8s/common/addons/custom
sudo chmod 755 /var/snap/microk8s/common/addons/custom

Configuration Override

Modify MicroK8s arguments:

# Edit kubelet arguments
sudo nano /var/snap/microk8s/current/args/kubelet

# Restart to apply changes
microk8s stop && microk8s start

MicroK8s on Ubuntu 24 provides an excellent balance of simplicity and functionality for Kubernetes development and edge deployments. Its snap-based distribution model ensures easy updates and consistent behavior across different environments. Whether you’re developing cloud-native applications, learning Kubernetes, or deploying edge workloads, MicroK8s offers a production-ready solution without the operational overhead of traditional Kubernetes distributions.

For more detailed information, check the official MicroK8s documentation and the Kubernetes documentation for deeper insights into cluster management and application deployment strategies.
