Mediator Design Pattern in Java – Example and Explanation

The Mediator Design Pattern solves the problem of tight coupling between objects by introducing a central coordinator that handles communication between components. Instead of objects directly referencing and calling each other, they communicate through a mediator, making the system more maintainable and flexible. This pattern is particularly useful in complex systems where multiple objects need to interact, and you’ll learn how to implement it in Java, understand common pitfalls, and see real-world applications in GUI frameworks, chat systems, and air traffic control systems.

How the Mediator Pattern Works

The Mediator pattern centralizes complex communications and control logic between related objects. Rather than having objects communicate directly, they communicate through the mediator, which acts as an intermediary. This reduces dependencies between communicating objects, thereby reducing coupling.

The pattern consists of four key components:

Mediator Interface – Defines the contract for communication between components
Concrete Mediator – Implements the mediator interface and coordinates communication
Colleague Interface – Defines the contract for components that participate in the mediated communication
Concrete Colleagues – Implement the colleague interface and communicate via the mediator

Here’s the basic structure in Java:

// Mediator interface
public interface ChatMediator {
    void sendMessage(String message, User user);
    void addUser(User user);
}

// Colleague interface
public abstract class User {
    protected ChatMediator mediator;
    protected String name;

    public User(ChatMediator mediator, String name) {
        this.mediator = mediator;
        this.name = name;
    }

    public abstract void send(String message);
    public abstract void receive(String message);
}

Step-by-Step Implementation Guide

Let’s build a complete chat room system to demonstrate the Mediator pattern. This example shows how multiple users can communicate through a central chat mediator without knowing about each other directly.

Step 1: Create the Mediator Interface

public interface ChatMediator {
    void sendMessage(String message, User user);
    void addUser(User user);
    void removeUser(User user);
    List<User> getUsers();
}

Step 2: Implement the Concrete Mediator

import java.util.ArrayList;
import java.util.List;

public class ChatMediatorImpl implements ChatMediator {
    private List<User> users;

    public ChatMediatorImpl() {
        this.users = new ArrayList<>();
    }

    @Override
    public void addUser(User user) {
        this.users.add(user);
        System.out.println(user.getName() + " joined the chat");
    }

    @Override
    public void removeUser(User user) {
        this.users.remove(user);
        System.out.println(user.getName() + " left the chat");
    }

    @Override
    public void sendMessage(String message, User user) {
        for (User u : this.users) {
            // Don't send message back to sender
            if (u != user) {
                u.receive(message);
            }
        }
    }

    @Override
    public List<User> getUsers() {
        return new ArrayList<>(users);
    }
}

Step 3: Create the Abstract Colleague Class

public abstract class User {
    protected ChatMediator mediator;
    protected String name;

    public User(ChatMediator mediator, String name) {
        this.mediator = mediator;
        this.name = name;
    }

    public abstract void send(String message);
    public abstract void receive(String message);

    public String getName() {
        return name;
    }
}

Step 4: Implement Concrete Colleagues

public class ChatUser extends User {

    public ChatUser(ChatMediator mediator, String name) {
        super(mediator, name);
    }

    @Override
    public void send(String message) {
        System.out.println(this.name + " sends: " + message);
        mediator.sendMessage(message, this);
    }

    @Override
    public void receive(String message) {
        System.out.println(this.name + " received: " + message);
    }
}

// Premium user with additional features
public class PremiumUser extends User {

    public PremiumUser(ChatMediator mediator, String name) {
        super(mediator, name);
    }

    @Override
    public void send(String message) {
        System.out.println("[PREMIUM] " + this.name + " sends: " + message);
        mediator.sendMessage(message, this);
    }

    @Override
    public void receive(String message) {
        System.out.println("[PREMIUM] " + this.name + " received: " + message);
    }

    public void sendPrivateMessage(String message, User targetUser) {
        System.out.println("[PRIVATE] " + this.name + " to " + targetUser.getName() + ": " + message);
        targetUser.receive("[PRIVATE from " + this.name + "]: " + message);
    }
}

Step 5: Test the Implementation

public class MediatorPatternDemo {
    public static void main(String[] args) {
        ChatMediator mediator = new ChatMediatorImpl();

        User user1 = new ChatUser(mediator, "Alice");
        User user2 = new ChatUser(mediator, "Bob");
        User user3 = new PremiumUser(mediator, "Charlie");

        mediator.addUser(user1);
        mediator.addUser(user2);
        mediator.addUser(user3);

        user1.send("Hello everyone!");
        user2.send("Hi Alice!");
        user3.send("Hey guys!");

        // Premium user sends private message
        if (user3 instanceof PremiumUser) {
            ((PremiumUser) user3).sendPrivateMessage("Secret message", user1);
        }
    }
}

Real-World Examples and Use Cases

The Mediator pattern appears in many real-world scenarios where you need to manage complex interactions between multiple components:

GUI Components Example

public class DialogMediator {
    private Button submitButton;
    private CheckBox termsCheckbox;
    private TextField emailField;

    public void componentChanged(Component component) {
        if (component == termsCheckbox) {
            submitButton.setEnabled(termsCheckbox.isChecked() &&
                                   !emailField.getText().isEmpty());
        } else if (component == emailField) {
            submitButton.setEnabled(termsCheckbox.isChecked() &&
                                   !emailField.getText().isEmpty());
        }
    }
}

Air Traffic Control System

public class AirTrafficControlTower implements AirTrafficMediator {
    private List<Aircraft> aircrafts = new ArrayList<>();

    @Override
    public void requestLanding(Aircraft aircraft) {
        // Check runway availability and coordinate with other aircraft
        for (Aircraft other : aircrafts) {
            if (other != aircraft && other.isLanding()) {
                aircraft.waitForLanding();
                return;
            }
        }
        aircraft.land();
    }

    @Override
    public void requestTakeoff(Aircraft aircraft) {
        // Similar coordination logic for takeoff
        aircraft.takeoff();
    }
}

Common real-world applications include:

Swing/JavaFX Applications – Managing interactions between UI components
Workflow Engines – Coordinating different steps in business processes
Game Development – Managing interactions between game objects
Microservices – API gateways acting as mediators between services
Event-Driven Systems – Message brokers like Apache Kafka or RabbitMQ

Comparison with Alternative Patterns

Pattern	Purpose	Communication Style	Coupling Level	Best Use Case
Mediator	Centralize complex communications	Many-to-one-to-many	Low between colleagues	Complex inter-object communication
Observer	Notify multiple objects of state changes	One-to-many	Low between subject and observers	Event notification systems
Command	Encapsulate requests as objects	Invoker to receiver	Low between invoker and receiver	Undo/redo functionality, queuing
Facade	Simplify complex subsystem	Client to subsystem	Low between client and subsystem	Simplifying complex APIs

Performance Comparison

Aspect	Direct Communication	Mediator Pattern	Observer Pattern
Memory Overhead	Low	Medium (mediator object)	Medium (observer list)
Message Passing Speed	Fastest	Medium (extra indirection)	Slower (multiple notifications)
Maintainability	Poor (tight coupling)	Excellent	Good
Scalability	Poor	Good	Excellent

Best Practices and Common Pitfalls

Best Practices:

Keep mediators focused – Don’t let your mediator become a god object handling everything
Use interfaces – Always define mediator contracts through interfaces for better testability
Consider async communication – For performance-critical applications, implement asynchronous message handling
Implement proper error handling – Mediators should gracefully handle failures in colleague communication
Use dependency injection – Inject mediators into colleagues rather than hard-coding dependencies

// Good practice: Async mediator with error handling
public class AsyncChatMediator implements ChatMediator {
    private ExecutorService executor = Executors.newFixedThreadPool(10);
    private List<User> users = Collections.synchronizedList(new ArrayList<>());

    @Override
    public void sendMessage(String message, User sender) {
        CompletableFuture.runAsync(() -> {
            users.parallelStream()
                 .filter(user -> user != sender)
                 .forEach(user -> {
                     try {
                         user.receive(message);
                     } catch (Exception e) {
                         System.err.println("Failed to deliver message to " + user.getName());
                     }
                 });
        }, executor);
    }
}

Common Pitfalls to Avoid:

Mediator becomes too complex – Split large mediators into smaller, specialized ones
Performance bottlenecks – All communication goes through mediator, so optimize carefully
Circular dependencies – Ensure colleagues don’t try to create or manage their mediators
Memory leaks – Properly remove colleagues from mediator when they’re no longer needed
Over-engineering – Don’t use mediator for simple two-object communications

Memory Management Example:

public class ImprovedChatMediator implements ChatMediator {
    private final WeakHashMap<User, Boolean> users = new WeakHashMap<>();

    @Override
    public void addUser(User user) {
        users.put(user, Boolean.TRUE);
    }

    @Override
    public void sendMessage(String message, User sender) {
        // WeakHashMap automatically removes garbage collected users
        users.keySet().stream()
             .filter(user -> user != sender)
             .forEach(user -> user.receive(message));
    }
}

Testing Considerations:

// Mock mediator for unit testing
public class MockChatMediator implements ChatMediator {
    private List<String> messageLog = new ArrayList<>();

    @Override
    public void sendMessage(String message, User user) {
        messageLog.add(user.getName() + ": " + message);
    }

    public List<String> getMessageLog() {
        return new ArrayList<>(messageLog);
    }

    public void clearLog() {
        messageLog.clear();
    }
}

The Mediator pattern shines in scenarios with complex inter-object communication but requires careful design to avoid creating monolithic mediator classes. Consider using it alongside other patterns like Observer for event notifications or Command for request queuing. For more detailed information about design patterns, check out the Oracle Java OOP tutorial and the Refactoring Guru design patterns guide.
