Log4j Levels Explained – Order, Priority, and Custom Filters

Log4j logging levels form the foundation of application logging strategy, determining which messages get recorded and which get ignored based on their severity and importance. Understanding the hierarchy, priority system, and how to implement custom filters can dramatically improve your debugging capabilities and application performance. This guide will walk you through the complete Log4j level system, from basic configuration to advanced filtering techniques that experienced developers use in production environments.

How Log4j Levels Work – The Technical Foundation

Log4j uses a hierarchical level system where each level has a numeric priority value. When you set a logging level for a logger, it will process all messages at that level and above, while filtering out messages below the threshold. The standard levels, from lowest to highest priority, are:

Level	Priority Value	Purpose	Performance Impact
TRACE	600	Fine-grained debug information	Highest overhead
DEBUG	500	General debugging information	High overhead
INFO	400	General application flow	Medium overhead
WARN	300	Potentially harmful situations	Low overhead
ERROR	200	Error events that allow application to continue	Minimal overhead
FATAL	100	Severe errors that cause application termination	Minimal overhead

The level inheritance works through the logger hierarchy. If you have a logger named “com.example.service” and set the root logger to WARN, this specific logger will inherit that level unless explicitly configured otherwise.

Step-by-Step Configuration Guide

Let’s start with basic Log4j2 configuration using XML. Create a log4j2.xml file in your classpath:

<?xml version="1.0" encoding="UTF-8"?>
<Configuration status="WARN">
  <Appenders>
    <Console name="Console" target="SYSTEM_OUT">
      <PatternLayout pattern="%d{HH:mm:ss.SSS} [%t] %-5level %logger{36} - %msg%n"/>
    </Console>
    <File name="FileAppender" fileName="logs/application.log">
      <PatternLayout pattern="%d{yyyy-MM-dd HH:mm:ss} %-5level %logger{36} - %msg%n"/>
    </File>
  </Appenders>

  <Loggers>
    <Logger name="com.example.database" level="DEBUG" additivity="false">
      <AppenderRef ref="FileAppender"/>
    </Logger>
    <Logger name="com.example.security" level="INFO" additivity="false">
      <AppenderRef ref="Console"/>
      <AppenderRef ref="FileAppender"/>
    </Logger>
    <Root level="WARN">
      <AppenderRef ref="Console"/>
    </Root>
  </Loggers>
</Configuration>

For programmatic configuration, you can set levels dynamically:

import org.apache.logging.log4j.LogManager;
import org.apache.logging.log4j.Logger;
import org.apache.logging.log4j.core.LoggerContext;
import org.apache.logging.log4j.core.config.Configuration;
import org.apache.logging.log4j.core.config.LoggerConfig;
import org.apache.logging.log4j.Level;

public class LogLevelManager {

    public static void setLogLevel(String loggerName, Level level) {
        LoggerContext context = (LoggerContext) LogManager.getContext(false);
        Configuration config = context.getConfiguration();
        LoggerConfig loggerConfig = config.getLoggerConfig(loggerName);
        loggerConfig.setLevel(level);
        context.updateLoggers();
    }

    public static void main(String[] args) {
        Logger logger = LogManager.getLogger("com.example.service");

        // Set to DEBUG level dynamically
        setLogLevel("com.example.service", Level.DEBUG);

        // Test different levels
        logger.trace("This is a trace message");
        logger.debug("This is a debug message");
        logger.info("This is an info message");
        logger.warn("This is a warning message");
        logger.error("This is an error message");
    }
}

Implementing Custom Filters

Custom filters give you granular control over log message processing beyond simple level-based filtering. Here’s how to create and implement various filter types:

Threshold Filter Example

<Configuration>
  <Appenders>
    <Console name="Console">
      <ThresholdFilter level="ERROR" onMatch="ACCEPT" onMismatch="DENY"/>
      <PatternLayout pattern="%d %-5level %logger - %msg%n"/>
    </Console>
    <File name="DebugFile" fileName="logs/debug.log">
      <ThresholdFilter level="DEBUG" onMatch="ACCEPT" onMismatch="DENY"/>
      <PatternLayout pattern="%d %-5level %logger - %msg%n"/>
    </File>
  </Appenders>
</Configuration>

Custom Filter Implementation

import org.apache.logging.log4j.core.Filter;
import org.apache.logging.log4j.core.LogEvent;
import org.apache.logging.log4j.core.config.plugins.Plugin;
import org.apache.logging.log4j.core.config.plugins.PluginAttribute;
import org.apache.logging.log4j.core.config.plugins.PluginFactory;
import org.apache.logging.log4j.core.filter.AbstractFilter;

@Plugin(name = "CustomFilter", category = "Core", elementType = "filter", printObject = true)
public class CustomFilter extends AbstractFilter {

    private final String keyword;

    private CustomFilter(String keyword, Filter.Result onMatch, Filter.Result onMismatch) {
        super(onMatch, onMismatch);
        this.keyword = keyword;
    }

    @Override
    public Filter.Result filter(LogEvent event) {
        String message = event.getMessage().getFormattedMessage();

        // Filter out messages containing sensitive information
        if (message.toLowerCase().contains(keyword.toLowerCase())) {
            return onMismatch;
        }

        return onMatch;
    }

    @PluginFactory
    public static CustomFilter createFilter(
            @PluginAttribute("keyword") String keyword,
            @PluginAttribute("onMatch") Filter.Result match,
            @PluginAttribute("onMismatch") Filter.Result mismatch) {

        return new CustomFilter(keyword, match != null ? match : Filter.Result.NEUTRAL,
                               mismatch != null ? mismatch : Filter.Result.DENY);
    }
}

Use this custom filter in your configuration:

<Configuration packages="com.example.filters">
  <Appenders>
    <Console name="Console">
      <CustomFilter keyword="password" onMatch="NEUTRAL" onMismatch="DENY"/>
      <PatternLayout pattern="%d %-5level %logger - %msg%n"/>
    </Console>
  </Appenders>
</Configuration>

Real-World Examples and Use Cases

Here are practical scenarios where proper level configuration and custom filters make a significant difference:

Microservices Architecture

In a microservices environment, you’ll want different logging strategies for different services. Here’s a production-ready configuration:

<Configuration>
  <Appenders>
    <RollingFile name="ServiceLogs" fileName="logs/service.log"
                 filePattern="logs/service-%d{yyyy-MM-dd}-%i.log.gz">
      <PatternLayout pattern="%d{ISO8601} [%t] %-5level %logger{36} [%X{traceId}] - %msg%n"/>
      <Policies>
        <TimeBasedTriggeringPolicy/>
        <SizeBasedTriggeringPolicy size="100MB"/>
      </Policies>
      <DefaultRolloverStrategy max="10"/>
    </RollingFile>

    <RollingFile name="ErrorLogs" fileName="logs/error.log"
                 filePattern="logs/error-%d{yyyy-MM-dd}-%i.log.gz">
      <ThresholdFilter level="ERROR" onMatch="ACCEPT" onMismatch="DENY"/>
      <PatternLayout pattern="%d{ISO8601} [%t] %-5level %logger{36} [%X{traceId}] - %msg%n%throwable"/>
      <Policies>
        <TimeBasedTriggeringPolicy/>
        <SizeBasedTriggeringPolicy size="50MB"/>
      </Policies>
    </RollingFile>
  </Appenders>

  <Loggers>
    <Logger name="com.example.auth" level="INFO"/>
    <Logger name="com.example.payment" level="WARN"/>
    <Logger name="com.example.notification" level="DEBUG"/>
    <Logger name="org.springframework" level="WARN"/>
    <Logger name="org.hibernate.SQL" level="DEBUG" additivity="false">
      <AppenderRef ref="ServiceLogs"/>
    </Logger>
    <Root level="INFO">
      <AppenderRef ref="ServiceLogs"/>
      <AppenderRef ref="ErrorLogs"/>
    </Root>
  </Loggers>
</Configuration>

High-Performance Applications

For applications where logging performance is critical, use asynchronous loggers with appropriate levels:

import org.apache.logging.log4j.LogManager;
import org.apache.logging.log4j.Logger;

public class PerformanceOptimizedLogging {
    private static final Logger logger = LogManager.getLogger();

    public void processOrder(Order order) {
        // Use level checks for expensive operations
        if (logger.isDebugEnabled()) {
            logger.debug("Processing order: {}", order.toDetailedString());
        }

        try {
            // Business logic here
            processPayment(order);
            logger.info("Order {} processed successfully", order.getId());
        } catch (PaymentException e) {
            logger.error("Payment failed for order {}: {}", order.getId(), e.getMessage());
            throw e;
        }
    }

    // Use markers for categorization
    private static final org.apache.logging.log4j.Marker PERFORMANCE =
        org.apache.logging.log4j.MarkerManager.getMarker("PERFORMANCE");

    public void logPerformanceMetric(String operation, long duration) {
        logger.info(PERFORMANCE, "Operation {} took {}ms", operation, duration);
    }
}

Performance Comparison and Best Practices

Here’s how different logging levels impact application performance based on typical enterprise application testing:

Configuration	Throughput (req/sec)	Memory Usage	Disk I/O	Recommended For
ERROR only	10,000	Low	Minimal	Production
WARN and above	9,500	Low	Low	Production
INFO and above	8,000	Medium	Medium	Staging/Production
DEBUG and above	4,000	High	High	Development/Testing
TRACE (all levels)	1,500	Very High	Very High	Deep debugging only

Best Practices for Production Environments

Set root logger to WARN or ERROR in production to minimize performance impact
Use specific logger configurations for critical components that need detailed logging
Implement log rotation to prevent disk space issues
Use asynchronous appenders for high-throughput applications
Always check log level before expensive string operations
Use structured logging with JSON format for better parsing and analysis
Implement custom filters to exclude sensitive information like passwords or API keys
Monitor log file sizes and implement alerting for unusual logging volume

Common Pitfalls and Troubleshooting

Level Inheritance Issues

One frequent mistake is misunderstanding logger inheritance. Consider this scenario:

// This won't work as expected
Logger rootLogger = LogManager.getLogger();
Logger specificLogger = LogManager.getLogger("com.example.service");

// If root is set to ERROR, but you expect DEBUG messages from specificLogger
// You need explicit configuration:

<Logger name="com.example.service" level="DEBUG">
    <AppenderRef ref="Console"/>
</Logger>

Performance Problems

Avoid this common performance killer:

// BAD - String concatenation happens regardless of level
logger.debug("User " + user.getName() + " performed " + action.getDescription());

// GOOD - Use parameterized messages
logger.debug("User {} performed {}", user.getName(), action.getDescription());

// BETTER - Check level for expensive operations
if (logger.isDebugEnabled()) {
    logger.debug("User {} performed {}", user.getName(), action.getComplexDescription());
}

Filter Configuration Mistakes

Filter order matters. Filters are processed in the order they appear:

<!-- WRONG - ThresholdFilter will never be reached -->
<Console name="Console">
    <RegexFilter regex=".*ERROR.*" onMatch="DENY" onMismatch="NEUTRAL"/>
    <ThresholdFilter level="ERROR" onMatch="ACCEPT" onMismatch="DENY"/>
</Console>

<!-- CORRECT - ThresholdFilter first, then RegexFilter -->
<Console name="Console">
    <ThresholdFilter level="ERROR" onMatch="NEUTRAL" onMismatch="DENY"/>
    <RegexFilter regex=".*ERROR.*" onMatch="DENY" onMismatch="ACCEPT"/>
</Console>
