How to Set Up an Nginx Ingress on DigitalOcean Kubernetes Using Helm

Setting up an Nginx Ingress Controller on DigitalOcean Kubernetes using Helm is a crucial skill for managing external access to your cluster services. This configuration acts as a reverse proxy and load balancer, handling HTTP and HTTPS traffic routing to your applications based on defined rules. You’ll learn how to deploy the ingress controller, configure SSL certificates, set up routing rules, and troubleshoot common issues that arise during implementation.

How Nginx Ingress Controller Works

The Nginx Ingress Controller operates as a specialized load balancer that runs inside your Kubernetes cluster. Unlike traditional external load balancers, it understands Kubernetes resources and can dynamically update its configuration based on Ingress resource definitions.

When you create an Ingress resource, the controller automatically generates the corresponding Nginx configuration and reloads the server. This process happens seamlessly without dropping existing connections. The controller watches for changes to Services, Endpoints, Secrets, and Configmaps, ensuring your routing rules stay synchronized with your cluster state.

Component	Function	Resource Type
Ingress Controller	Nginx process that handles traffic	Deployment
Ingress Resource	Configuration rules for routing	Custom Resource
Load Balancer Service	External IP allocation	Service

Prerequisites and Initial Setup

Before diving into the installation, ensure you have these components ready:

A running DigitalOcean Kubernetes cluster with kubectl access
Helm 3.x installed and configured
Basic understanding of Kubernetes services and deployments
Domain name pointing to your cluster (for SSL configuration)

First, verify your cluster connection and install Helm if you haven’t already:

kubectl cluster-info
kubectl get nodes

# Install Helm (if not already installed)
curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash
helm version

Step-by-Step Installation Guide

Start by adding the official Nginx Ingress Helm repository:

helm repo add ingress-nginx https://kubernetes.github.io/ingress-nginx
helm repo update

Create a namespace for the ingress controller to keep things organized:

kubectl create namespace ingress-nginx

Now install the Nginx Ingress Controller with DigitalOcean-specific configurations:

helm install ingress-nginx ingress-nginx/ingress-nginx \
  --namespace ingress-nginx \
  --set controller.service.type=LoadBalancer \
  --set controller.service.annotations."service\.beta\.kubernetes\.io/do-loadbalancer-enable-proxy-protocol"=true \
  --set controller.config.use-proxy-protocol=true \
  --set controller.service.annotations."service\.beta\.kubernetes\.io/do-loadbalancer-hostname"=your-domain.com

The installation process takes a few minutes as DigitalOcean provisions a load balancer. Monitor the progress:

kubectl get services -n ingress-nginx -w

Once you see an external IP assigned, your ingress controller is ready. The output should look similar to:

NAME                                 TYPE           CLUSTER-IP      EXTERNAL-IP      PORT(S)
ingress-nginx-controller             LoadBalancer   10.245.xxx.xxx  139.59.xxx.xxx   80:32080/TCP,443:32443/TCP

Configuring Your First Ingress Resource

Create a sample application to test your ingress setup. Here’s a simple nginx deployment:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: test-app
spec:
  replicas: 2
  selector:
    matchLabels:
      app: test-app
  template:
    metadata:
      labels:
        app: test-app
    spec:
      containers:
      - name: nginx
        image: nginx:latest
        ports:
        - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  name: test-app-service
spec:
  selector:
    app: test-app
  ports:
  - port: 80
    targetPort: 80

Save this as `test-app.yaml` and apply it:

kubectl apply -f test-app.yaml

Now create an Ingress resource to route traffic to your application:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: test-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
  - host: your-domain.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: test-app-service
            port:
              number: 80

Apply the ingress configuration:

kubectl apply -f ingress.yaml

SSL Certificate Management with Cert-Manager

For production environments, SSL certificates are essential. The most efficient approach uses cert-manager with Let’s Encrypt:

helm repo add jetstack https://charts.jetstack.io
helm repo update

kubectl create namespace cert-manager

helm install cert-manager jetstack/cert-manager \
  --namespace cert-manager \
  --version v1.13.0 \
  --set installCRDs=true

Create a ClusterIssuer for Let’s Encrypt:

apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
  name: letsencrypt-prod
spec:
  acme:
    server: https://acme-v02.api.letsencrypt.org/directory
    email: your-email@domain.com
    privateKeySecretRef:
      name: letsencrypt-prod
    solvers:
    - http01:
        ingress:
          class: nginx

Update your Ingress resource to include TLS configuration:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: test-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
    cert-manager.io/cluster-issuer: letsencrypt-prod
spec:
  ingressClassName: nginx
  tls:
  - hosts:
    - your-domain.com
    secretName: your-domain-tls
  rules:
  - host: your-domain.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: test-app-service
            port:
              number: 80

Advanced Configuration Options

The Nginx Ingress Controller offers extensive customization through annotations and ConfigMaps. Here are some commonly used configurations:

Feature	Annotation	Example Value
Rate Limiting	nginx.ingress.kubernetes.io/rate-limit	100
CORS Headers	nginx.ingress.kubernetes.io/enable-cors	true
Upload Size	nginx.ingress.kubernetes.io/proxy-body-size	50m
Basic Auth	nginx.ingress.kubernetes.io/auth-type	basic

For global configurations, create a ConfigMap:

apiVersion: v1
kind: ConfigMap
metadata:
  name: nginx-config
  namespace: ingress-nginx
data:
  proxy-connect-timeout: "10"
  proxy-read-timeout: "120"
  proxy-send-timeout: "120"
  server-tokens: "false"

Real-World Use Cases and Examples

Multi-Service Application Routing

A common scenario involves routing different paths to different services:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: multi-service-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /$2
spec:
  ingressClassName: nginx
  rules:
  - host: myapp.com
    http:
      paths:
      - path: /api(/|$)(.*)
        pathType: Prefix
        backend:
          service:
            name: api-service
            port:
              number: 8080
      - path: /frontend(/|$)(.*)
        pathType: Prefix
        backend:
          service:
            name: frontend-service
            port:
              number: 80

Blue-Green Deployments

Use traffic splitting for gradual rollouts:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: canary-ingress
  annotations:
    nginx.ingress.kubernetes.io/canary: "true"
    nginx.ingress.kubernetes.io/canary-weight: "10"
spec:
  ingressClassName: nginx
  rules:
  - host: myapp.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: app-v2-service
            port:
              number: 80

Performance Tuning and Best Practices

Monitor your ingress controller performance using these metrics:

kubectl top pods -n ingress-nginx
kubectl get --raw /metrics | grep nginx

For high-traffic environments, consider these optimizations:

Increase replica count for the ingress controller
Configure resource limits and requests appropriately
Enable HTTP/2 and gzip compression
Use connection pooling and keep-alive settings
Implement proper caching strategies

Update your Helm values for production workloads:

helm upgrade ingress-nginx ingress-nginx/ingress-nginx \
  --namespace ingress-nginx \
  --set controller.replicaCount=3 \
  --set controller.resources.requests.cpu=100m \
  --set controller.resources.requests.memory=90Mi \
  --set controller.resources.limits.cpu=500m \
  --set controller.resources.limits.memory=500Mi

Troubleshooting Common Issues

External IP Not Assigned

If your LoadBalancer service shows `` for the external IP:

kubectl describe service ingress-nginx-controller -n ingress-nginx
kubectl get events -n ingress-nginx --sort-by='.lastTimestamp'

This usually indicates DigitalOcean load balancer provisioning issues or quota limits.

SSL Certificate Issues

Check cert-manager logs and certificate status:

kubectl logs -n cert-manager deployment/cert-manager
kubectl describe certificate your-domain-tls
kubectl describe challengerequest

503 Service Temporarily Unavailable

This error typically means your backend service isn’t responding:

kubectl get endpoints
kubectl logs -n ingress-nginx deployment/ingress-nginx-controller

Verify your service selectors match your pod labels exactly.

Comparison with Alternative Solutions

Solution	Pros	Cons	Best For
Nginx Ingress	Feature-rich, battle-tested, extensive customization	Resource intensive, complex configuration	Production environments
Traefik	Automatic service discovery, modern architecture	Smaller community, fewer examples	Microservices, Docker environments
DigitalOcean LB	Managed service, minimal setup	Limited customization, vendor lock-in	Simple applications

For high-availability setups on dedicated servers, consider running multiple ingress controllers across different nodes with anti-affinity rules.

Security Considerations

Implement these security measures for production deployments:

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: ingress-nginx-policy
  namespace: ingress-nginx
spec:
  podSelector:
    matchLabels:
      app.kubernetes.io/name: ingress-nginx
  policyTypes:
  - Ingress
  - Egress
  ingress:
  - from: []
    ports:
    - protocol: TCP
      port: 80
    - protocol: TCP
      port: 443

Additional security configurations:

Enable ModSecurity WAF with OWASP rules
Configure rate limiting and DDoS protection
Use authentication middlewares for sensitive endpoints
Implement IP whitelisting for admin interfaces
Regular security updates and monitoring

The combination of DigitalOcean Kubernetes and Nginx Ingress provides a robust foundation for hosting production applications. For smaller deployments, consider VPS solutions as a cost-effective alternative.

Remember to regularly update your ingress controller and monitor its performance metrics. The official Nginx Ingress documentation provides comprehensive guidance for advanced configurations and troubleshooting scenarios.
