How to Migrate MySQL Database to Postgres Using pgloader

How to Migrate MySQL Database to Postgres Using pgloader

Migrating from MySQL to PostgreSQL is a common challenge that many teams face when scaling applications or seeking better performance, advanced features, and more robust data integrity constraints. While manual migration can be tedious and error-prone, pgloader provides an automated solution that can handle the heavy lifting of data transfer, schema conversion, and type mapping between these two popular database systems. This guide will walk you through the complete process of using pgloader to migrate your MySQL database to PostgreSQL, covering everything from installation and configuration to troubleshooting common issues and optimizing performance.

Understanding pgloader and How It Works

pgloader is a powerful data loading tool specifically designed to migrate data into PostgreSQL from various source databases, including MySQL, SQLite, MS SQL Server, and CSV files. What makes pgloader particularly effective for MySQL-to-PostgreSQL migrations is its ability to automatically handle schema differences, data type conversions, and even rebuild indexes and constraints.

The tool works by connecting to both source and destination databases simultaneously, reading the MySQL schema structure, converting it to PostgreSQL-compatible DDL statements, and then streaming data in batches. It handles complex scenarios like foreign key relationships, triggers, and custom data types that would otherwise require manual intervention.

Key advantages of pgloader include:

  • Automatic schema conversion with intelligent type mapping
  • Parallel data loading for improved performance
  • Built-in error handling and data validation
  • Support for custom transformation rules
  • Comprehensive logging and progress reporting

Unlike simple dump-and-restore approaches, pgloader can transform data on-the-fly, making it ideal for migrations where direct schema compatibility isn’t possible.

Installation and Initial Setup

Getting pgloader up and running depends on your operating system. Here are the most common installation methods:

Ubuntu/Debian:

sudo apt-get update
sudo apt-get install pgloader

CentOS/RHEL:

sudo yum install epel-release
sudo yum install pgloader

macOS (using Homebrew):

brew install pgloader

Docker (recommended for consistent environments):

docker pull dimitri/pgloader:latest

Before starting the migration, ensure both MySQL and PostgreSQL servers are accessible and you have the necessary permissions. You’ll need:

  • READ access to the MySQL source database
  • CREATE and INSERT permissions on the PostgreSQL target database
  • Network connectivity between pgloader and both database servers

Test your connections first:

# Test MySQL connection
mysql -h source_host -u username -p source_database

# Test PostgreSQL connection
psql -h target_host -U username -d target_database

Step-by-Step Migration Process

The migration process with pgloader involves creating a command file that defines source and target connections, transformation rules, and migration parameters.

Basic Migration Command

For simple migrations, you can use pgloader’s command-line syntax:

pgloader mysql://user:password@mysql-host/source_db postgresql://user:password@pg-host/target_db

However, for production environments, using a configuration file provides better control:

Creating a Configuration File

Create a file named migration.load:

LOAD DATABASE
    FROM mysql://mysql_user:mysql_pass@mysql_host:3306/source_database
    INTO postgresql://pg_user:pg_pass@pg_host:5432/target_database

WITH include drop, create tables, create indexes, reset sequences,
     workers = 8, concurrency = 1,
     multiple readers per thread, rows per range = 50000

SET MySQL PARAMETERS
    net_read_timeout  = '120s',
    net_write_timeout = '120s'

SET PostgreSQL PARAMETERS
    maintenance_work_mem to '1GB',
    checkpoint_segments to 64

CAST type datetime to timestamptz
     drop default drop not null using zero-dates-to-null,
     type date drop not null drop default using zero-dates-to-null

BEFORE LOAD DO
$$ CREATE EXTENSION IF NOT EXISTS "uuid-ossp"; $$

ALTER SCHEMA 'source_database' RENAME TO 'public';

Running the Migration

Execute the migration using your configuration file:

pgloader migration.load

For Docker users:

docker run --rm -v $(pwd):/data dimitri/pgloader:latest pgloader /data/migration.load

Advanced Configuration Options

For complex migrations, you might need additional configuration options:

LOAD DATABASE
    FROM mysql://user:pass@mysql-host/source_db
    INTO postgresql://user:pass@pg-host/target_db

WITH include drop, create tables, create indexes, reset sequences,
     workers = 16, concurrency = 1,
     multiple readers per thread, rows per range = 100000,
     prefetch rows = 25000

SET MySQL PARAMETERS
    net_read_timeout = '300s',
    net_write_timeout = '300s'

-- Handle specific table transformations
LOAD FROM mysql_table
INTO postgresql_table (
    id, name, created_at, updated_at
)
WITH truncate,
     skip header = 1,
     fields optionally enclosed by '"',
     fields escaped by double-quote,
     fields terminated by ','

-- Custom data transformations
CAST column "price" to numeric drop typemod,
     column "status" to text,
     column "created_date" to timestamp using zero-dates-to-null

Real-World Migration Examples

E-commerce Platform Migration

Here’s a practical example of migrating an e-commerce database with complex relationships:

LOAD DATABASE
    FROM mysql://ecom_user:secure_pass@mysql.internal:3306/ecommerce_prod
    INTO postgresql://pg_user:pg_pass@postgres.internal:5432/ecommerce_new

WITH include drop, create tables, create indexes, reset sequences,
     workers = 12, concurrency = 1,
     multiple readers per thread, rows per range = 25000

-- Handle decimal precision for prices
CAST type decimal(10,2) to numeric(10,2),
     type tinyint(1) to boolean using tinyint-to-boolean,
     type datetime to timestamptz drop default drop not null using zero-dates-to-null

-- Pre-migration setup
BEFORE LOAD DO
$$
CREATE EXTENSION IF NOT EXISTS "uuid-ossp";
CREATE EXTENSION IF NOT EXISTS "pg_trgm";
$$

-- Handle specific tables with custom logic
EXCLUDING TABLE NAMES MATCHING ~/^temp_/, ~/^backup_/

-- Custom field mapping for user table
LOAD FROM users
INTO users (
    user_id, email, password_hash,
    created_at, updated_at, last_login
)
WITH batch rows = 10000,
     batch size = 20MB

-- Post-migration tasks
AFTER LOAD DO
$$
UPDATE products SET search_vector = to_tsvector('english', name || ' ' || description);
CREATE INDEX CONCURRENTLY idx_products_search ON products USING gin(search_vector);
$$;

Multi-Tenant Application Migration

For applications with multiple schemas or tenant separation:

-- Migrate each tenant schema separately
LOAD DATABASE
    FROM mysql://app_user:password@mysql-host/tenant_001
    INTO postgresql://pg_user:password@pg-host/multi_tenant_app

WITH include drop, create tables, create indexes,
     workers = 8

ALTER SCHEMA 'tenant_001' RENAME TO 'tenant_001'

-- Repeat for each tenant or use shell scripting
-- for tenant in tenant_001 tenant_002 tenant_003; do
--   sed "s/TENANT_NAME/$tenant/g" migration_template.load > ${tenant}_migration.load
--   pgloader ${tenant}_migration.load
-- done

Performance Optimization and Tuning

Migration performance can vary significantly based on data volume, network latency, and hardware resources. Here are key optimization strategies:

Parameter Default Value Recommended for Large DBs Impact
workers 4 8-16 Parallel processing threads
rows per range 25000 50000-100000 Batch size for data transfer
prefetch rows 10000 25000-50000 Read-ahead buffer size
multiple readers per thread false true Concurrent reading capability

PostgreSQL-specific optimizations during migration:

SET PostgreSQL PARAMETERS
    maintenance_work_mem to '2GB',
    checkpoint_segments to 128,
    wal_buffers to '16MB',
    shared_buffers to '4GB',
    effective_cache_size to '12GB'

Performance monitoring during migration:

# Monitor pgloader progress
tail -f /tmp/pgloader.log

# Check PostgreSQL activity
SELECT pid, query, state, query_start
FROM pg_stat_activity
WHERE datname = 'target_database';

# Monitor table sizes during migration
SELECT schemaname, tablename,
       pg_size_pretty(pg_total_relation_size(schemaname||'.'||tablename)) as size
FROM pg_tables
WHERE schemaname = 'public'
ORDER BY pg_total_relation_size(schemaname||'.'||tablename) DESC;

Common Issues and Troubleshooting

Data Type Conversion Problems

MySQL and PostgreSQL handle certain data types differently. Common issues include:

Zero dates and timestamps:

-- MySQL allows '0000-00-00' dates, PostgreSQL doesn't
CAST type datetime to timestamptz
     drop default drop not null using zero-dates-to-null,

-- Alternative: use a specific default date
CAST type datetime to timestamptz
     using zero-dates-to-epoch

Boolean values:

-- Convert MySQL tinyint(1) to PostgreSQL boolean
CAST type tinyint(1) to boolean using tinyint-to-boolean

Text encoding issues:

-- Handle character set conversion
SET MySQL PARAMETERS
    character_set_client = 'utf8mb4',
    character_set_connection = 'utf8mb4'

Memory and Performance Issues

Large tables can cause memory issues. Solutions include:

-- Reduce batch sizes for memory-constrained environments
WITH workers = 4, concurrency = 1,
     rows per range = 10000,
     prefetch rows = 5000

-- Process large tables separately
EXCLUDING TABLE NAMES MATCHING ~/^large_table_/

-- Then process large tables individually with custom settings

Connection and Network Problems

Timeout issues are common with large migrations:

SET MySQL PARAMETERS
    net_read_timeout = '600s',
    net_write_timeout = '600s',
    interactive_timeout = '28800s',
    wait_timeout = '28800s'

SET PostgreSQL PARAMETERS
    statement_timeout to '0',
    lock_timeout to '0'

Foreign Key and Constraint Issues

Handle referential integrity carefully:

-- Disable foreign key checks during migration
BEFORE LOAD DO
$$
SET session_replication_role = replica;
$$

AFTER LOAD DO
$$
SET session_replication_role = DEFAULT;

-- Validate all foreign key constraints
DO $$
DECLARE
    r RECORD;
BEGIN
    FOR r IN SELECT constraint_name, table_name
             FROM information_schema.table_constraints
             WHERE constraint_type = 'FOREIGN KEY'
    LOOP
        EXECUTE 'ALTER TABLE ' || r.table_name || ' VALIDATE CONSTRAINT ' || r.constraint_name;
    END LOOP;
END
$$;
$$

Comparing pgloader with Alternative Migration Tools

Tool Pros Cons Best Use Case
pgloader Automatic schema conversion, parallel processing, built-in error handling Limited customization for complex transformations Straightforward MySQL to PostgreSQL migrations
AWS DMS Cloud-native, continuous replication, minimal downtime AWS ecosystem lock-in, complex pricing Cloud migrations with ongoing replication needs
mysqldump + custom scripts Full control, free, works everywhere Manual schema conversion, time-consuming, error-prone Small databases or highly customized migrations
Pentaho/Talend GUI interface, complex transformations, enterprise features Steep learning curve, licensing costs Enterprise environments with complex data transformations

Best Practices and Production Considerations

Pre-Migration Checklist

  • Perform a complete backup of source MySQL database
  • Test migration on a subset of data first
  • Document all custom functions, procedures, and triggers
  • Identify and plan for application-specific SQL query changes
  • Set up monitoring for both source and target databases
  • Plan for downtime and coordinate with stakeholders

Security Considerations

Never expose database credentials in plain text:

# Use environment variables
export MYSQL_URL="mysql://user:pass@host/db"
export PG_URL="postgresql://user:pass@host/db"

# Then reference in pgloader config
LOAD DATABASE FROM ${MYSQL_URL} INTO ${PG_URL}

Or use PostgreSQL’s password file:

# Create ~/.pgpass file
hostname:port:database:username:password

# Set restrictive permissions
chmod 600 ~/.pgpass

Post-Migration Validation

Always validate your migration results:

-- Compare row counts
SELECT 'users' as table_name, COUNT(*) as row_count FROM users
UNION ALL
SELECT 'orders' as table_name, COUNT(*) as row_count FROM orders;

-- Validate data integrity
SELECT COUNT(*) as orphaned_orders
FROM orders o
LEFT JOIN users u ON o.user_id = u.id
WHERE u.id IS NULL;

-- Check for null values in required fields
SELECT COUNT(*) as null_emails
FROM users
WHERE email IS NULL;

-- Verify indexes are created
SELECT schemaname, tablename, indexname, indexdef
FROM pg_indexes
WHERE schemaname = 'public'
ORDER BY tablename, indexname;

Application Migration Considerations

Remember that migrating data is only part of the process. Applications may need updates for:

  • SQL syntax differences (LIMIT vs LIMIT/OFFSET)
  • Date/time handling differences
  • Case sensitivity in column names
  • Boolean value representation
  • Auto-increment vs sequences

For more detailed information about pgloader’s capabilities and advanced configuration options, refer to the official pgloader documentation. The PostgreSQL wiki also provides excellent resources on database migration best practices.

Migration projects can be complex, but pgloader significantly simplifies the process of moving from MySQL to PostgreSQL. With proper planning, testing, and the techniques outlined in this guide, you can achieve a successful migration with minimal downtime and data integrity issues. Remember to always test thoroughly in a staging environment before proceeding with production migrations.
