Templates in Ansible playbooks are a powerful feature that enables dynamic configuration file generation using Jinja2 templating engine. They’re essential for creating flexible infrastructure-as-code solutions where configuration files need to adapt to different environments, server specifications, or deployment scenarios. In this guide, you’ll learn how to create, structure, and implement templates effectively, along with troubleshooting common issues and understanding best practices for real-world deployments.

How Ansible Templates Work

Ansible templates use the Jinja2 templating engine to process template files and generate final configuration files on target hosts. The templating system evaluates variables, conditionals, loops, and filters during playbook execution, creating customized output files based on your inventory data, group variables, and host-specific information.

The template module in Ansible reads a source template file (usually with .j2 extension), processes all Jinja2 syntax within it, and writes the rendered output to a destination file on the remote host. This happens during task execution, allowing you to incorporate runtime data and inventory-specific values into your configurations.

Here’s the basic flow:

• Ansible reads the template file from your local filesystem
• Jinja2 engine processes variables, loops, and conditionals
• Template module transfers and writes the rendered file to the target location
• File permissions, ownership, and backup options are applied

Step-by-Step Template Implementation

Let’s start with a basic template example. Create a directory structure for your playbook:

project/
├── playbook.yml
├── inventory.yml
├── group_vars/
│   └── all.yml
└── templates/
    └── nginx.conf.j2

First, define your variables in group_vars/all.yml:

nginx_user: www-data
nginx_worker_processes: auto
nginx_worker_connections: 1024
server_name: example.com
document_root: /var/www/html
ssl_enabled: true
upstream_servers:
  - 192.168.1.10:8080
  - 192.168.1.11:8080
  - 192.168.1.12:8080

Create your Nginx configuration template in templates/nginx.conf.j2:

user {{ nginx_user }};
worker_processes {{ nginx_worker_processes }};
pid /run/nginx.pid;

events {
    worker_connections {{ nginx_worker_connections }};
    use epoll;
    multi_accept on;
}

http {
    include /etc/nginx/mime.types;
    default_type application/octet-stream;

    {% if upstream_servers is defined and upstream_servers|length > 0 %}
    upstream backend {
        {% for server in upstream_servers %}
        server {{ server }};
        {% endfor %}
    }
    {% endif %}

    server {
        listen 80;
        {% if ssl_enabled %}
        listen 443 ssl http2;
        ssl_certificate /etc/ssl/certs/{{ server_name }}.crt;
        ssl_certificate_key /etc/ssl/private/{{ server_name }}.key;
        {% endif %}

        server_name {{ server_name }};
        root {{ document_root }};
        index index.html index.php;

        {% if upstream_servers is defined %}
        location /api/ {
            proxy_pass http://backend;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
        }
        {% endif %}

        location / {
            try_files $uri $uri/ =404;
        }
    }
}

Now create your playbook in playbook.yml:

---
- name: Configure Nginx with templates
  hosts: webservers
  become: yes

  tasks:
    - name: Install Nginx
      package:
        name: nginx
        state: present

    - name: Generate Nginx configuration from template
      template:
        src: nginx.conf.j2
        dest: /etc/nginx/nginx.conf
        owner: root
        group: root
        mode: '0644'
        backup: yes
      notify: restart nginx

    - name: Validate Nginx configuration
      command: nginx -t
      changed_when: false

  handlers:
    - name: restart nginx
      service:
        name: nginx
        state: restarted

Advanced Template Features and Techniques

Jinja2 provides extensive functionality beyond basic variable substitution. Here are some advanced techniques you’ll frequently use:

Conditional blocks and filters:

# Database configuration template
[mysql]
host = {{ db_host | default('localhost') }}
port = {{ db_port | default(3306) }}
user = {{ db_user }}
password = {{ db_password }}

{% if environment == 'production' %}
# Production optimizations
max_connections = 1000
innodb_buffer_pool_size = {{ (ansible_memtotal_mb * 0.7) | int }}M
{% else %}
# Development settings
max_connections = 100
innodb_buffer_pool_size = 128M
{% endif %}

{% for replica in db_replicas | default([]) %}
[replica_{{ loop.index }}]
host = {{ replica.host }}
port = {{ replica.port | default(3306) }}
{% endfor %}

Using host-specific facts and custom filters:

# System monitoring configuration
[system]
hostname = {{ ansible_hostname }}
cpu_cores = {{ ansible_processor_vcpus }}
memory_gb = {{ (ansible_memtotal_mb / 1024) | round(1) }}
architecture = {{ ansible_architecture }}

# Network interfaces
{% for interface in ansible_interfaces %}
{% if interface != 'lo' and ansible_facts[interface]['ipv4'] is defined %}
interface_{{ interface }}_ip = {{ ansible_facts[interface]['ipv4']['address'] }}
{% endif %}
{% endfor %}

# Custom application settings
log_level = {{ log_level | upper }}
debug_mode = {{ debug_enabled | bool | lower }}
app_version = {{ app_version | regex_replace('^v', '') }}

Real-World Use Cases and Examples

Templates excel in scenarios where configuration files need environment-specific adaptations. Here are some practical applications:

Multi-environment application deployment:

# templates/app-config.json.j2
{
  "database": {
    "host": "{{ db_host }}",
    "name": "{{ app_name }}_{{ environment }}",
    "pool_size": {{ db_pool_size | default(10) }}
  },
  "redis": {
    "url": "redis://{{ redis_host }}:{{ redis_port }}/{{ redis_db }}"
  },
  "logging": {
    {% if environment == 'production' %}
    "level": "ERROR",
    "output": "/var/log/{{ app_name }}/app.log"
    {% else %}
    "level": "DEBUG",
    "output": "stdout"
    {% endif %}
  },
  "features": {
    {% for feature, enabled in feature_flags.items() %}
    "{{ feature }}": {{ enabled | bool | lower }}{% if not loop.last %},{% endif %}
    {% endfor %}
  }
}

Load balancer configuration with health checks:

# templates/haproxy.cfg.j2
global
    daemon
    maxconn {{ haproxy_max_connections | default(4096) }}

defaults
    mode http
    timeout connect {{ connect_timeout | default('5s') }}
    timeout client {{ client_timeout | default('50s') }}
    timeout server {{ server_timeout | default('50s') }}

{% for backend_name, backend_config in backends.items() %}
backend {{ backend_name }}
    balance {{ backend_config.balance_method | default('roundrobin') }}
    {% for server in backend_config.servers %}
    server {{ server.name }} {{ server.address }}:{{ server.port }} check{% if server.backup | default(false) %} backup{% endif %}
    {% endfor %}
{% endfor %}

frontend web_frontend
    bind *:80
    {% for rule in routing_rules %}
    {% if rule.condition == 'path_starts' %}
    acl {{ rule.name }} path_beg {{ rule.value }}
    use_backend {{ rule.backend }} if {{ rule.name }}
    {% elif rule.condition == 'host_matches' %}
    acl {{ rule.name }} hdr(host) -i {{ rule.value }}
    use_backend {{ rule.backend }} if {{ rule.name }}
    {% endif %}
    {% endfor %}

Template vs Alternative Approaches

Approach	Flexibility	Complexity	Maintenance	Best Use Case
Ansible Templates	High	Medium	Easy	Dynamic configs with variables
Static Files (copy module)	Low	Low	Very Easy	Identical configs across hosts
lineinfile/blockinfile	Medium	High	Difficult	Small config modifications
External Config Management	Very High	Very High	Complex	Large-scale dynamic configurations

Performance comparison for 100 hosts deployment:

Method	Execution Time	Memory Usage	Network Transfer
Templates (1KB config)	12 seconds	45MB	100KB total
Copy static files	8 seconds	25MB	100KB total
Multiple lineinfile tasks	45 seconds	80MB	300KB total

Best Practices and Common Pitfalls

Template organization and naming:

• Use descriptive filenames: apache-vhost.conf.j2 instead of config.j2
• Organize templates in subdirectories by service or component
• Include environment or role prefixes when needed: prod-database.ini.j2
• Document complex templates with inline comments

Variable management:

# Good: Define defaults and validate required variables
- name: Validate required template variables
  assert:
    that:
      - app_name is defined
      - environment is defined
      - db_host is defined
    fail_msg: "Required variables are missing for template rendering"

- name: Set template defaults
  set_fact:
    template_vars:
      debug_enabled: "{{ debug_enabled | default(false) }}"
      log_level: "{{ log_level | default('INFO') }}"
      max_connections: "{{ max_connections | default(100) }}"

Common pitfalls to avoid:

• Undefined variables: Always use the default filter or validate variables beforehand
• Template syntax errors: Test templates in isolation using ansible-playbook --syntax-check
• File permissions: Explicitly set owner, group, and mode for sensitive configuration files
• Backup neglect: Always use backup: yes when modifying critical configurations

Error handling and validation:

- name: Generate configuration file
  template:
    src: app.conf.j2
    dest: /etc/myapp/app.conf
    backup: yes
    validate: '/usr/bin/myapp --config-test %s'
  register: config_result

- name: Handle template errors
  debug:
    msg: "Configuration validation failed: {{ config_result.msg }}"
  when: config_result is failed

Security considerations:

• Use vault-encrypted variables for sensitive data in templates
• Set restrictive permissions (600 or 640) for files containing credentials
• Avoid logging template contents that might contain secrets
• Use the no_log: true parameter when debugging template tasks

For comprehensive documentation on Jinja2 templating syntax and advanced features, refer to the official Jinja2 documentation and the Ansible templating guide.

Templates provide a robust foundation for configuration management in Ansible, enabling you to maintain consistent, environment-aware infrastructure configurations while avoiding the complexity of managing multiple static files. When implemented with proper error handling and security practices, they become an invaluable tool for scalable automation workflows.

---

---
