Setting up WireGuard involves configuring a server and client. In this guide, we’ll walk through setting up a basic WireGuard server and client. This example uses a Linux-based system, but the process is somewhat similar across other platforms.
1. Install WireGuard:
On a Debian/Ubuntu Server:
sudo apt update
sudo apt install wireguard
On a CentOS/RHEL Server:
First, enable the EPEL repository:
sudo yum install epel-release -y
Then, install WireGuard:
sudo yum install wireguard-dkms wireguard-tools -y
2. Server Configuration:
Generate Server Keys:
cd /etc/wireguard/
umask 077
wg genkey | tee server_private_key | wg pubkey > server_public_key
Create and Edit Server Configuration:
nano /etc/wireguard/wg0.conf
Enter the following, adjusting as necessary:
[Interface]
Address = 10.0.0.1/24
ListenPort = 51820
PrivateKey = [YourServerPrivateKeyFromAbove]PublicKey = [YourClientPublicKey]
AllowedIPs = 10.0.0.2/32
3. Client Configuration:
Generate Client Keys:
This step can be performed on the server for simplicity, or directly on the client.
wg genkey | tee client_private_key | wg pubkey > client_public_key
Create and Edit Client Configuration:
If you’re on the client:
nano /etc/wireguard/wg0.conf
Enter the following, adjusting as necessary:
[Interface]
Address = 10.0.0.2/24
PrivateKey = [YourClientPrivateKeyFromAbove]PublicKey = [YourServerPublicKey]
Endpoint = [YourServerIPAddress]:51820
AllowedIPs = 0.0.0.0/0
PersistentKeepalive = 25
4. Start and Enable WireGuard:
On the Server:
sudo wg-quick up wg0
sudo systemctl enable wg-quick@wg0
On the Client:
sudo wg-quick up wg0
sudo systemctl enable wg-quick@wg0
5. Test the Connection:
From the client, you should be able to ping the server using its WireGuard IP:
ping 10.0.0.1
Final Notes:
- Always replace placeholders like
[YourServerPrivateKeyFromAbove]with the actual values. - The server’s
AllowedIPsfor the client is restrictive to only allow the client’s WireGuard IP. If you add more clients, add more[Peer]sections to the server config and adjust IPs accordingly. - The client’s
AllowedIPsis set to0.0.0.0/0, which means all traffic will be routed through the VPN. Adjust this if you need split tunneling. - The
PersistentKeepalivesetting helps with NAT/firewall traversal. - Ensure your server’s firewall allows incoming connections on the chosen WireGuard port (51820 in this case). Adjust firewall settings as necessary.
- This is a basic setup; there are many other configurations possible based on your needs. Always remember to secure and monitor your server.
